Wireless Pump Controls Remote Long Range Radio Control

	Wireless Controls and Automation

Compact Wireless Radio Controls

Single Channel Budget Radio system

■ Specifications

Operation:
Channel 1 Closure Output 1 ON
Channel 1 Opening Output 1 OFF

Migro433-1

Part 943312 12VDC
Part 943324 24VDC
Part 943327 120/240VAC

■ To Order

Specifications Digital Transmitter

Supply power	12 VDC @ 400 mA
Inputs	N/O Normally Open, digital dry contact
Transmitter power	per FCC Part 15.249, 50mV/m @ 3m
Transmission	Digital Encoded Gaussian_frequency-shift_keying
Channels	16 addresses per system GFSK
Input Wiring	Din Terminals, Dry Contact
Response	Loop 500 msec
Weight	2.2 lb (1.10kg) each unit
Dimensions	9 x 9 x 3.5 in. / (230.00 x 230.00 x 90.00 mm)

Specifications Digital Receiver

Supply power	12 VDC @ 300 mA
Output	Relay SPST contact 6.Amp, 30V/240vac Class 2 pilot duty
Frequency	433 MHz • License free Industrial ISM band
Configuration	DIP switch factory preset
Compliance	FCC CFR part 15.247, 95 sub E
Wiring	Components mounted on 35mm DIN rail
Antenna Z	50 Ohm SMA RF connector
Ambient temp	14° to 140° F (-10° to 60° C)
DIN Rail	IP22, UL94-5VA, DIN mount 35mm or panel mount

System is supplied with Two Omni Antenna 938091 Short Range

Wireless Range: 5 Km ( 3 Miles )
Optional Extended Range 16 Km (10 Miles) +

Wireless Control Specifications

Start Stop - 2 Channel

■ Specifications

Operation :
• Channel 1 Closure Starts Output 1 ON
• Channel 2 Closure Stops Output 1 OFF

Migro433-2

Part 943341 12VDC
Part 943342 24VDC
Part 943347 120/240VAC

■ To Order

Performance
• 360m (1200ft) line-of-sight w 6 inch antenna
• Operation: 120/240VAC or 12VDC
• Transmitter input N/O Dry contact
• Relay Output SPDT, 6A Class 2 pilot duty
• Heavy Duty NEMA4, IP65 UL Fiber enclosure
• License free 430 - 450MHz Industrial ISM band
• Factory configured systems, Ready to operate
• No setup or programming required

Antenna Selection ( TWO are required )

938432 Yagi antenna 3 E

7 dBi 2 Mile+
Length: 18", Weight: 1.lb
with 10 ft coax cable and connector

Antenna Selection

938438 Omni directional antenna

3 dBi 1 Mile+
Length: 37", Weight: 3.lb
with 10 ft coax cable and connector

Antenna Selection

■ Unlimited Applications

Industrial remotes, Pump control, Lighting control, Monitoring level, status, Traffic systems, Door and Gates, Logistics, Packing and mobile system, Water management, Alarms, Remote conveyors, Marinas stand alone lights, Remote tank level operation, Generators, Notification, Solar Controllers, Oil and Gas line Monitoring, Flood alarm, Signs, Irrigation control, Wire Replacement.

■ Wide Selection:

1 Extended Range Radios 27

2 Single & Two Ch Pump Control 154

3 Handheld Wireless Long Range 160

4 Bidirectional Wireless Control

5 Budget Radio Systems 433

6 Long Range OEM Selection

7 Command & Monitoring System 154

8 Wireless Applications

9 Repeater Options: Solar

10 WIFi 4 Channel Controller

DISCLAIMER: Radio control equipment in not to be used in life safety.
Radio Installations shall be performed by a certified professional.
