Contactor


 Industrial Contactor 3 Pole 4 Pole


933210

50 Amp. AC-1, 32 Amp. AC-3

3 Pole  Normally Open (N.O.) contacts 600V

50A. Incandescent, LED or resistive load
 32A. Motor control, 20HP@ 480VAC
Auxiliary contact  1NO/1NC
Power Lug Terminal Capacity AWG # 4

Coil 110/120VAC
Details     Specifications



933210  120VAC $36.99


934060

60 Amp.  4 Pole  (Silent Operation)

Normally Open (N.O.) contacts
 For 120/220/277/Rated 400V,


10HP @240V, 20HP @460V
 40A. Ballast, 12KW@ 220VAC
Dimension: 2.2w x 3.3h x 2.5d inch
 63Amp AC-1,  40Amp AC-3
Power Lug Terminal Capacity AWG # 4
Auxiliary Contact  1 NC /1 NO  5Amp.
Coil 110/120VAC
Specifications

934060A  120VAC  $99.99





100 AMP LIGHTING CONTACTOR 4 Pole 120V Coil    (Silent Operation)




100 Amp.  4 Pole
NORMALLY OPEN  --]  [--

 Normally Open (N.O.) contacts
 For 120/220/277/Rated 500V,
 10HP @240V, 30HP @460V
 60A. Ballast, 15 KW@ 220VAC
 100Amp AC-1,  60Amp AC-3
Coil: Inrush 87VA, Sealed 22VA
Certified CE, EN, IEC 61095.  Not UL listed
Power Lug Terminal Capacity AWG # 2/0
Coil 110/120VAC  Add DIN rail

Dimensions

934100  N/O

 120VAC    OUT of Stock






100 Amp.  4 Pole
NORMALLY
CLOSED   --] /[--

 Normally Close (N.C.) contacts
 For 120/220/277/Rated 500V,
 10HP @240V, 30HP @460V
 60A. Ballast, 15 KW@ 220VAC
 100Amp AC-1,  60Amp AC-3
Coil: Inrush 87VA, Sealed 22VA
Certified
CE, EN, IEC 61095.  Not UL listed
Power Lug Terminal Capacity AWG # 2/0
Coil 110/120VAC   Add DIN rail

Dimensions

934101  N/C

 120VAC    OUT of Stock
