Hermetically Sealed Contactors 35, 60 & 100 Amps.




Contactors are hermetically sealed with high quality glass to metal seals.
This provides more precise process temperature control and eliminates
the noise from the on-off operating cycles of electro-mechanical relays and contactors.

The stainless steel tube is totally encapsulated in high grade UL approved epoxy protective coating.
Low coil power required to actuate the contactor.
Applications:
Transfer Switch, Solar Panel Switch, Duct heaters, Baseboard heaters, Pool heaters, Motor control, Flood lights, High intensity lamps, Mercury vapor lighting, Sodium vapor lighting, Tungsten lamps, Corrosive locations, Dusty, oily locations, High cycle rate application,
 Installation manual


General Specifications:

Contact Voltage: 120, 240, & 480 VAC, Inductive, 600VAC Resistive
Contact Rating DC  60A@48VDC,   30A@125VDC
Operate time 50 ms, Release time 80 ms
Encapsulated Sealed mercury contacts, Operation in the upright position only
Dielectric withstand 2500 VAC RMS,  Longevity Millions of cycles
Temperature range -31° to 185°F (-35° to 85°C)
Contact terminals pressure connectors for AWG #4-14
Each Coil rating 5.8 VA, Optional coil voltage: 24,208,220,277,480VAC or 12,24,48,125 VDC (price may vary)
Approvals: UL listed, file #E62767; CSA certified, file #LR41198

Other coil voltages and 4 poles available upon Request
SPECIAL ORDER  ITEM

To ORDER


NORMALLY OPEN  (NO)

NORMALLY CLOSED (NC)

..........................35 Amp  (Resistive)

Price

35NO-120

35NC-120

Single pole 35 amp 120V AC coil

$129.95

235NO-120

235NC-120

Two pole 35 amp 120V AC coil

$229.95

335NO-120

335NC-120

Three pole 35 amp 120V AC coil

$269.99


NORMALLY OPEN  (NO)

NORMALLY CLOSED (NC)

..........................60 Amp   (Resistive)

Price

60NO-120

60NC-120

Single pole 60 amp 120V AC coil

$229.95

260NO-120

260NC-120

Two pole 60 amp 120V AC coil

$339.95

360NO-120

360NC-120

Three pole 60 amp 120V AC coil

$439.95


NORMALLY OPEN  (NO)

NORMALLY CLOSED (NC)

..........................100 Amp   (Resistive)

Price

100NO-120

100NC-120

Single pole 100 amp 120V AC coil

$499.95

2100NO-120

2100NC-120

Two pole 100 amp 120V AC coil

$749.95

3100NO-120

3100NC-120

Three pole 100 amp 120V AC coil

$859.95

Single pole Two pole  Three pole

DISCLAIMER:  NOTE: Please contact a certified professional for the installation,
